Expected Behaviour:
Trying to install Pi-hole in Docker which is on an Openmediavault server.
Followed the install guide on this video: Block ads on your whole network with Pi-hole and Openmediavault - YouTube
Stuck on the step where I have to log onto the web interface.
Actual Behaviour:
web interface refuses to connect. in this case http://192.168.1.202/admin
Debug Token:
e[95m*** [ INITIALIZING ]e[0m
[i] 2019-12-24:17:22:37 debug log has been initialized.
e[95m*** [ INITIALIZING ]e[0m Sourcing setup variables
[i] Sourcing /etc/pihole/setupVars.conf...
e[95m*** [ DIAGNOSING ]:e[0m Core version
[i] Core: e[33mv4.3.2e[0m (e[96mhttps://discourse.pi-hole.net/t/how-do-i-update-pi-hole/249e[0m)
[i] Branch: e[32mmastere[0m
[i] Commit: v4.3.2-0-ge41c4b5
e[95m*** [ DIAGNOSING ]:e[0m Web version
[i] Web: e[33mv4.3.2e[0m (e[96mhttps://discourse.pi-hole.net/t/how-do-i-update-pi-hole/249e[0m)
[i] Branch: e[32mmastere[0m
[i] Commit: v4.3.2-0-g38d8e77
e[95m*** [ DIAGNOSING ]:e[0m FTL version
[e[32m✓e[0m] FTL: e[32mv4.3.1e[0m
e[95m*** [ DIAGNOSING ]:e[0m lighttpd version
[i] 1.4.45
e[95m*** [ DIAGNOSING ]:e[0m php version
[i] 7.0.33
e[95m*** [ DIAGNOSING ]:e[0m Operating system
[e[32m✓e[0m] e[32mDebian GNU/Linux 9 (stretch)e[0m
e[95m*** [ DIAGNOSING ]:e[0m SELinux
[i] e[32mSELinux not detectede[0m
e[95m*** [ DIAGNOSING ]:e[0m Processor
[i] x86_64
e[95m*** [ DIAGNOSING ]:e[0m Networking
[e[32m✓e[0m] IPv4 address(es) bound to the eth0 interface:
e[91m192.168.1.202/24e[0m does not match the IP found in /etc/pihole/setupVars.conf (e[96mhttps://discourse.pi-hole.net/t/use-ipv6-ula-addresses-for-pi-hole/2127e[0m)
[e[91m✗e[0m] e[91mNo IPv6 address(es) found on the eth0e[0m interface.
[i] Default IPv4 gateway: 192.168.1.1
* Pinging 192.168.1.1...
[e[32m✓e[0m] e[32mGateway responded.e[0m
e[95m*** [ DIAGNOSING ]:e[0m Ports in use
[e[32m*:53e[0m] is in use by e[32mpihole-FTLe[0m
[e[32m*:53e[0m] is in use by e[32mpihole-FTLe[0m
[e[32m127.0.0.1:4711e[0m] is in use by e[32mpihole-FTLe[0m
e[95m*** [ DIAGNOSING ]:e[0m Name resolution (IPv4) using a random blocked domain and a known ad-serving domain
[e[32m✓e[0m] www.cool-premiums.com e[32mis 0.0.0.0e[0m via e[96mlocalhoste[0m (127.0.0.1)
[e[32m✓e[0m] www.cool-premiums.com e[32mis 0.0.0.0e[0m via e[96mPi-holee[0m (192.168.1.202)
[e[32m✓e[0m] doubleclick.com e[32mis 216.58.199.78e[0m via e[96ma remote, public DNS servere[0m (8.8.8.8)
e[95m*** [ DIAGNOSING ]:e[0m Pi-hole processes
[e[91m✗e[0m] e[91mlighttpde[0m daemon is e[91minactivee[0m
[e[91m✗e[0m] e[91mpihole-FTLe[0m daemon is e[91minactivee[0m
e[95m*** [ DIAGNOSING ]:e[0m Setup variables
BLOCKING_ENABLED=true
QUERY_LOGGING=true
INSTALL_WEB_SERVER=true
INSTALL_WEB_INTERFACE=true
LIGHTTPD_ENABLED=
IPV4_ADDRESS=192.168.1.202
IPV6_ADDRESS=
DNS_BOGUS_PRIV=
DNSSEC=
CONDITIONAL_FORWARDING=
CONDITIONAL_FORWARDING_IP=
CONDITIONAL_FORWARDING_DOMAIN=
CONDITIONAL_FORWARDING_REVERSE=
PIHOLE_DNS_1=8.8.8.8
PIHOLE_DNS_2=8.8.4.4
PIHOLE_INTERFACE=eth0
e[95m*** [ DIAGNOSING ]:e[0m Dashboard and block page
[e[32m✓e[0m] Block page X-Header: e[32mX-Pi-hole: A black hole for Internet advertisements.e[0m
[e[32m✓e[0m] Web interface X-Header: e[32mX-Pi-hole: The Pi-hole Web interface is working!e[0m
e[95m*** [ DIAGNOSING ]:e[0m Gravity list
e[32m-rw-r--r-- 1 root root 2658965 Dec 24 17:02 /etc/pihole/gravity.liste[0m
e[96m-----head of gravity.list------e[0m
0.0.0.0
0.nextyourcontent.com
0.r.msn.com
0.start.bz
e[96m-----tail of gravity.list------e[0m
zzz.clickbank.net
zzzezeroe.fr
zzzpooeaz-france.com
zzzrtrcm2.com
e[95m*** [ DIAGNOSING ]:e[0m contents of e[96m/etc/piholee[0m
e[32m-rw-r--r-- 1 root root 313 Dec 24 16:09 /etc/pihole/adlists.liste[0m
https://raw.githubusercontent.com/StevenBlack/hosts/master/hosts
https://mirror1.malwaredomains.com/files/justdomains
http://sysctl.org/cameleon/hosts
https://s3.amazonaws.com/lists.disconnect.me/simple_tracking.txt
https://s3.amazonaws.com/lists.disconnect.me/simple_ad.txt
https://hosts-file.net/ad_servers.txt
e[32m-rw-r--r-- 1 root root 53 Dec 24 17:02 /etc/pihole/local.liste[0m
192.168.1.202 tomeofknowledge2
192.168.1.202 pi.hole
e[95m*** [ DIAGNOSING ]:e[0m contents of e[96m/etc/dnsmasq.de[0m
e[32m-rw-r--r-- 1 root root 1387 Dec 24 17:01 /etc/dnsmasq.d/01-pihole.confe[0m
addn-hosts=/etc/pihole/gravity.list
addn-hosts=/etc/pihole/black.list
addn-hosts=/etc/pihole/local.list
localise-queries
no-resolv
cache-size=10000
log-queries
log-facility=/var/log/pihole.log
local-ttl=2
log-async
server=8.8.8.8
server=8.8.4.4
interface=eth0
e[95m*** [ DIAGNOSING ]:e[0m contents of e[96m/etc/lighttpde[0m
e[32m-rw-r--r-- 1 root root 3499 Dec 24 17:01 /etc/lighttpd/lighttpd.confe[0m
server.modules = (
"mod_access",
"mod_accesslog",
"mod_auth",
"mod_expire",
"mod_compress",
"mod_redirect",
"mod_setenv",
"mod_rewrite"
)
server.document-root = "/var/www/html"
server.error-handler-404 = "/pihole/index.php"
server.upload-dirs = ( "/var/cache/lighttpd/uploads" )
server.errorlog = "/var/log/lighttpd/error.log"
server.pid-file = "/var/run/lighttpd.pid"
server.username = "www-data"
server.groupname = "www-data"
server.port = 80
accesslog.filename = "/var/log/lighttpd/access.log"
accesslog.format = "%{%s}t|%V|%r|%s|%b"
index-file.names = ( "index.php", "index.html", "index.lighttpd.html" )
url.access-deny = ( "~", ".inc", ".md", ".yml", ".ini" )
static-file.exclude-extensions = ( ".php", ".pl", ".fcgi" )
compress.cache-dir = "/var/cache/lighttpd/compress/"
compress.filetype = ( "application/javascript", "text/css", "text/html", "text/plain" )
mimetype.assign = ( ".png" => "image/png",
".jpg" => "image/jpeg",
".jpeg" => "image/jpeg",
".html" => "text/html",
".css" => "text/css; charset=utf-8",
".js" => "application/javascript",
".json" => "application/json",
".txt" => "text/plain",
".svg" => "image/svg+xml" )
include_shell "/usr/share/lighttpd/use-ipv6.pl " + server.port
include_shell "find /etc/lighttpd/conf-enabled -name '*.conf' -a ! -name 'letsencrypt.conf' -printf 'include \"%p\"
' 2>/dev/null"
$HTTP["url"] =~ "^/admin/" {
setenv.add-response-header = (
"X-Pi-hole" => "The Pi-hole Web interface is working!",
"X-Frame-Options" => "DENY"
)
$HTTP["url"] =~ ".ttf$" {
setenv.add-response-header = ( "Access-Control-Allow-Origin" => "*" )
}
}
$HTTP["url"] =~ "^/admin/\.(.*)" {
url.access-deny = ("")
}
include_shell "cat external.conf 2>/dev/null"
e[95m*** [ DIAGNOSING ]:e[0m contents of e[96m/etc/cron.de[0m
e[32m-rw-r--r-- 1 root root 1704 Sep 23 06:05 /etc/cron.d/piholee[0m
44 4 * * 7 root PATH="$PATH:/usr/local/bin/" pihole updateGravity >/var/log/pihole_updateGravity.log || cat /var/log/pihole_updateGravity.log
00 00 * * * root PATH="$PATH:/usr/local/bin/" pihole flush once quiet
@reboot root /usr/sbin/logrotate /etc/pihole/logrotate
*/10 * * * * root PATH="$PATH:/usr/local/bin/" pihole updatechecker local
37 12 * * * root PATH="$PATH:/usr/local/bin/" pihole updatechecker remote
@reboot root PATH="$PATH:/usr/local/bin/" pihole updatechecker remote reboot
e[95m*** [ DIAGNOSING ]:e[0m contents of e[96m/var/log/lighttpde[0m
e[32m-rw-r--r-- 1 www-data www-data 49 Dec 24 17:02 /var/log/lighttpd/error.loge[0m
2019-12-24 17:02:00: (log.c.217) server started
e[95m*** [ DIAGNOSING ]:e[0m contents of e[96m/var/loge[0m
e[32m-rw-r--r-- 1 root root 8624 Dec 24 17:02 /var/log/pihole-FTL.loge[0m
e[96m-----head of pihole-FTL.log------e[0m
[2019-12-24 17:01:51.686 325] Using log file /var/log/pihole-FTL.log
[2019-12-24 17:01:51.686 325] ########## FTL started! ##########
[2019-12-24 17:01:51.686 325] FTL branch: master
[2019-12-24 17:01:51.686 325] FTL version: v4.3.1
[2019-12-24 17:01:51.686 325] FTL commit: b60d63f
[2019-12-24 17:01:51.686 325] FTL date: 2019-05-25 21:37:26 +0200
[2019-12-24 17:01:51.687 325] FTL user: root
[2019-12-24 17:01:51.687 325] Starting config file parsing (/etc/pihole/pihole-FTL.conf)
[2019-12-24 17:01:51.687 325] SOCKET_LISTENING: only local
[2019-12-24 17:01:51.687 325] AAAA_QUERY_ANALYSIS: Show AAAA queries
[2019-12-24 17:01:51.687 325] MAXDBDAYS: max age for stored queries is 365 days
[2019-12-24 17:01:51.687 325] RESOLVE_IPV6: Resolve IPv6 addresses
[2019-12-24 17:01:51.687 325] RESOLVE_IPV4: Resolve IPv4 addresses
[2019-12-24 17:01:51.687 325] DBINTERVAL: saving to DB file every minute
[2019-12-24 17:01:51.687 325] DBFILE: Using /etc/pihole/pihole-FTL.db
[2019-12-24 17:01:51.687 325] MAXLOGAGE: Importing up to 24.0 hours of log data
[2019-12-24 17:01:51.687 325] PRIVACYLEVEL: Set to 0
[2019-12-24 17:01:51.687 325] IGNORE_LOCALHOST: Show queries from localhost
[2019-12-24 17:01:51.687 325] BLOCKINGMODE: Null IPs for blocked domains
[2019-12-24 17:01:51.687 325] ANALYZE_ONLY_A_AND_AAAA: Disabled. Analyzing all queries
[2019-12-24 17:01:51.687 325] DBIMPORT: Importing history from database
[2019-12-24 17:01:51.688 325] PIDFILE: Using /var/run/pihole-FTL.pid
[2019-12-24 17:01:51.688 325] PORTFILE: Using /var/run/pihole-FTL.port
[2019-12-24 17:01:51.688 325] SOCKETFILE: Using /var/run/pihole/FTL.sock
[2019-12-24 17:01:51.688 325] WHITELISTFILE: Using /etc/pihole/whitelist.txt
[2019-12-24 17:01:51.688 325] BLACKLISTFILE: Using /etc/pihole/black.list
[2019-12-24 17:01:51.688 325] GRAVITYFILE: Using /etc/pihole/gravity.list
[2019-12-24 17:01:51.688 325] REGEXLISTFILE: Using /etc/pihole/regex.list
[2019-12-24 17:01:51.688 325] SETUPVARSFILE: Using /etc/pihole/setupVars.conf
[2019-12-24 17:01:51.688 325] AUDITLISTFILE: Using /etc/pihole/auditlog.list
[2019-12-24 17:01:51.688 325] MACVENDORDB: Using /etc/pihole/macvendor.db
[2019-12-24 17:01:51.688 325] PARSE_ARP_CACHE: Active
[2019-12-24 17:01:51.688 325] Finished config file parsing
[2019-12-24 17:01:51.689 325] WARNING: Starting pihole-FTL as user root is not recommended
[2019-12-24 17:01:51.690 325] Database version is 3
e[96m-----tail of pihole-FTL.log------e[0m
[2019-12-24 17:02:00.602 498] WHITELISTFILE: Using /etc/pihole/whitelist.txt
[2019-12-24 17:02:00.602 498] BLACKLISTFILE: Using /etc/pihole/black.list
[2019-12-24 17:02:00.602 498] GRAVITYFILE: Using /etc/pihole/gravity.list
[2019-12-24 17:02:00.602 498] REGEXLISTFILE: Using /etc/pihole/regex.list
[2019-12-24 17:02:00.602 498] SETUPVARSFILE: Using /etc/pihole/setupVars.conf
[2019-12-24 17:02:00.602 498] AUDITLISTFILE: Using /etc/pihole/auditlog.list
[2019-12-24 17:02:00.602 498] MACVENDORDB: Using /etc/pihole/macvendor.db
[2019-12-24 17:02:00.602 498] PARSE_ARP_CACHE: Active
[2019-12-24 17:02:00.602 498] Finished config file parsing
[2019-12-24 17:02:00.602 498] WARNING: Starting pihole-FTL as user root is not recommended
[2019-12-24 17:02:00.603 498] Database version is 3
[2019-12-24 17:02:00.603 498] Database successfully initialized
[2019-12-24 17:02:00.603 498] New forward server: 8.8.4.4 (0/512)
[2019-12-24 17:02:00.603 498] New forward server: 8.8.8.8 (1/512)
[2019-12-24 17:02:00.603 498] Imported 28 queries from the long-term database
[2019-12-24 17:02:00.603 498] -> Total DNS queries: 28
[2019-12-24 17:02:00.603 498] -> Cached DNS queries: 8
[2019-12-24 17:02:00.603 498] -> Forwarded DNS queries: 20
[2019-12-24 17:02:00.603 498] -> Exactly blocked DNS queries: 0
[2019-12-24 17:02:00.603 498] -> Unknown DNS queries: 0
[2019-12-24 17:02:00.603 498] -> Unique domains: 3
[2019-12-24 17:02:00.603 498] -> Unique clients: 1
[2019-12-24 17:02:00.603 498] -> Known forward destinations: 2
[2019-12-24 17:02:00.603 498] Successfully accessed setupVars.conf
[2019-12-24 17:02:00.603 498] *************************************************************************
[2019-12-24 17:02:00.603 498] * WARNING: Required Linux capability CAP_NET_ADMIN not available *
[2019-12-24 17:02:00.603 498] *************************************************************************
[2019-12-24 17:02:00.895 498] PID of FTL process: 498
[2019-12-24 17:02:00.895 498] Listening on port 4711 for incoming IPv4 telnet connections
[2019-12-24 17:02:00.895 498] Listening on Unix socket
[2019-12-24 17:02:00.896 498] Received SIGHUP, reloading cache
[2019-12-24 17:02:00.896 498] Blocking status is enabled
[2019-12-24 17:02:00.896 498] INFO: No whitelist file found
[2019-12-24 17:02:00.896 498] Compiled 0 Regex filters and 0 whitelisted domains in 0.0 msec (0 errors)
[2019-12-24 17:02:01.462 498] /etc/pihole/gravity.list: parsed 113624 domains (took 565.1 ms)
e[95m*** [ DIAGNOSING ]:e[0m contents of e[96m/dev/shme[0m
-rw------- 1 root root 331776 Dec 24 17:02 /dev/shm/FTL-clients
-rw------- 1 root root 108 Dec 24 17:02 /dev/shm/FTL-counters
-rw------- 1 root root 98304 Dec 24 17:02 /dev/shm/FTL-domains
-rw------- 1 root root 20480 Dec 24 17:02 /dev/shm/FTL-forwarded
-rw------- 1 root root 48 Dec 24 17:02 /dev/shm/FTL-lock
-rw------- 1 root root 12288 Dec 24 17:02 /dev/shm/FTL-overTime
-rw------- 1 root root 229376 Dec 24 17:02 /dev/shm/FTL-queries
-rw------- 1 root root 12 Dec 24 17:02 /dev/shm/FTL-settings
-rw------- 1 root root 4096 Dec 24 17:02 /dev/shm/FTL-strings
e[95m*** [ DIAGNOSING ]:e[0m Locale
LANG=
e[95m*** [ DIAGNOSING ]:e[0m Pi-hole log
e[32m-rw-r--r-- 1 pihole pihole 7440 Dec 24 17:22 /var/log/pihole.loge[0m
e[96m-----head of pihole.log------e[0m
Dec 24 17:01:52 dnsmasq[327]: started, version pi-hole-2.80 cachesize 10000
Dec 24 17:01:52 dnsmasq[327]: compile time options: IPv6 GNU-getopt no-DBus no-i18n no-IDN DHCP DHCPv6 no-Lua TFTP no-conntrack ipset auth DNSSEC loop-detect inotify dumpfile
Dec 24 17:01:52 dnsmasq[327]: using nameserver 8.8.4.4#53
Dec 24 17:01:52 dnsmasq[327]: using nameserver 8.8.8.8#53
Dec 24 17:01:52 dnsmasq[327]: read /etc/hosts - 7 addresses
Dec 24 17:01:52 dnsmasq[327]: read /etc/pihole/local.list - 2 addresses
Dec 24 17:01:52 dnsmasq[327]: failed to load names from /etc/pihole/black.list: No such file or directory
Dec 24 17:01:52 dnsmasq[327]: read /etc/pihole/gravity.list - 113624 addresses
Dec 24 17:02:00 dnsmasq[498]: started, version pi-hole-2.80 cachesize 10000
Dec 24 17:02:00 dnsmasq[498]: compile time options: IPv6 GNU-getopt no-DBus no-i18n no-IDN DHCP DHCPv6 no-Lua TFTP no-conntrack ipset auth DNSSEC loop-detect inotify dumpfile
Dec 24 17:02:00 dnsmasq[498]: using nameserver 8.8.4.4#53
Dec 24 17:02:00 dnsmasq[498]: using nameserver 8.8.8.8#53
Dec 24 17:02:00 dnsmasq[498]: read /etc/hosts - 7 addresses
Dec 24 17:02:00 dnsmasq[498]: read /etc/pihole/local.list - 2 addresses
Dec 24 17:02:00 dnsmasq[498]: failed to load names from /etc/pihole/black.list: No such file or directory
Dec 24 17:02:01 dnsmasq[498]: read /etc/pihole/gravity.list - 113624 addresses
Dec 24 17:02:19 dnsmasq[498]: query[A] pi.hole from 127.0.0.1
Dec 24 17:02:19 dnsmasq[498]: /etc/pihole/local.list pi.hole is 192.168.1.202
Dec 24 17:02:49 dnsmasq[498]: query[A] pi.hole from 127.0.0.1
Dec 24 17:02:49 dnsmasq[498]: /etc/pihole/local.list pi.hole is 192.168.1.202
e[95m********************************************e[0m
e[95m********************************************e[0m
[e[32m✓e[0m] e[32m** FINISHED DEBUGGING! **e[0m
