Above looks wrong and should look like below:
Above sounds as if the WiFi interface is still active and trying to acquire an IP via DHCP.
Is Raspbian/Pi-OS installed?
What model Pi do you have?
What driver modules are loaded?
Maybe you need the "
dtoverlay=pi3-disable-wifi" from below instead of "
If trying above, after a reboot, check with
lsmod if a driver is missing now.
FYI, my Pi3 loads below driver for wifi:
pi@arcade:~ $ lsmod
Module Size Used by
brcmfmac 307200 0
pi@arcade:~ $ modinfo brcmfmac
license: Dual BSD/GPL
description: Broadcom 802.11 wireless LAN fullmac driver.
pi@arcade:~ $ dmesg -T | grep brcmfmac
[Wed Jan 19 01:32:16 2022] brcmfmac: F1 signature read @0x18000000=0xXXXXX
[Wed Jan 19 01:32:16 2022] brcmfmac: brcmf_fw_map_chip_to_name: using brcm/brcmfmac43430-sdio.bin for chip 0x00a9a6(43430) rev 0x000001
[Wed Jan 19 01:32:16 2022] usbcore: registered new interface driver brcmfmac
[Wed Jan 19 01:32:16 2022] brcmfmac: brcmf_c_preinit_dcmds: Firmware version = wl0: Oct 23 2017 03:55:53 version 220.127.116.11 (r674442 CY) FWID 01-e58d219f
[Wed Jan 19 01:32:16 2022] brcmfmac: brcmf_c_preinit_dcmds: CLM version = API: 12.2 Data: 7.11.15 Compiler: 1.24.2 ClmImport: 1.24.1 Creation: 2014-05-26 10:53:55 Inc Data: 9.10.39 Inc Compiler: 1.29.4 Inc ClmImport: 1.36.3 Creation: 2017-10-23 03:47:14
[Wed Jan 19 01:32:17 2022] brcmfmac: power management disabled
Some more tools for diagnosing, below one shows interface links (including MAC addresses):
ip -br l
Below one IP's:
ip -br a
Below one the journals for the
dhcpcd network manager:
journalctl -u dhcpcd
Below one shows DHCP log entries:
grep dnsmasq-dhcp /var/log/pihole.log
Above sounds like another issue.
First fix the current ones and if still experience above issue, create a new help request/topic/thread pls?
EDIT: Come to think of it, you've posted similar mistakes in
dhcpcd.conf twice already.
Makes me wonder if
dhcpcd is just ignoring that
dhcpcd.conf file bc of errors and does what it do default without configuration, acquire an IP via DHCP for all detected interfaces including the
EDIT2: With below one you can restart
dhcpcd if corrected the
sudo service dhcpcd restart
And check journals after!
