Reverse lookup of client ips

Help
1

Please follow the below template, it will help us to help you!

Expected Behaviour:

I'd like the dashboard and etc., to show client DNS names, via reverse lookup.

Actual Behaviour:

But I'm actually seeing just ip addresses.

Clients via Win Server DHCP are told pihole.agpllc.local is the DNS server. athena.agpllc.local is the Win Server, and has the reverse entries. If I do a reverse lookup via pihole, it works right (below), but /etc/resolv.conf has just the Google DNS entries 8.8.8.8 8.8.4.4, and that yields NXDOMAIN (below).

Perhaps this is a misconfiguration on my part? Something I need to do? BTW, I'm not entirely sure I had the dnsmasq.d file set right to begin with, but it is now (below)

reverse lookup via pihole

[root@pihole log]# nslookup
> server pihole.agpllc.local
Default server: pihole.agpllc.local
Address: fe80::20c:29ff:fefc:d662#53
Default server: pihole.agpllc.local
Address: 192.168.55.34#53
> 192.168.55.1
Server:         pihole.agpllc.local
Address:        fe80::20c:29ff:fefc:d662#53

1.55.168.192.in-addr.arpa       name = athena.agpllc.local.

Reverse lookup via default resolver

[root@pihole log]# nslookup
> 192.168.55.1
Server:         8.8.8.8
Address:        8.8.8.8#53

** server can't find 1.55.168.192.in-addr.arpa.: NXDOMAIN
>

/etc/dnsmasq.d/06-activedirectory.conf:

[root@pihole dnsmasq.d]# cat 06-activedirectory.conf
## Point to Athena for .agpllc.local addresses
## amg 2018 06 29
server=/agpllc.local/192.168.55.1
server=/55.168.192.in-addr.arpa/192.168.55.1

Debug Token:

Your debug token is: r7oi3e3pcf

4

in the pihole webgui under setting and DNS look at the 5 options conditional forwarding and p[otentially the other options there should resolve this issue.

5

Set the Pi-hole's /etc/resolv.conf to 127.0.0.1 so it uses its own DNS server.

6

I can't find a way for NetworkManager to stop rewriting resolv.conf. Centos 7, btw.

7

in the pihole webgui under setting and DNS look at the 5 options conditional forwarding and p[otentially the other options there should resolve this issue.

Yea, nope. Unticking both boxes yields no difference.

8

According to this, modify the ifcfg- file for you interface and set it to use localhost for DNS:

9

Yea, I found that.

  1. It doesn't work, even removing the DNS1 and DNS2 entries from ifcfg-eth0 doesn't stop NetworkManager from overwriting (it puts a 'search ' line in resolv.conf even if it isn't putting nameserver lines in).

  2. Nevermind that, if I manually edit resolv.conf and then verify that nslookup is pulling from the right nameserver, I still can't see reverse-lookedup names in the dashboard or in reports... do I need to refresh something, or delete logs, or something?

    [root@pihole network-scripts]# cat /etc/resolv.conf
    nameserver 127.0.0.1
    [root@pihole network-scripts]# nslookup

    192.168.55.1
    Server: 127.0.0.1
    Address: 127.0.0.1#53

    Non-authoritative answer:
    1.55.168.192.in-addr.arpa name = athena.agpllc.local.

    Authoritative answers can be found from:

    exit

    [root@pihole network-scripts]#

10

That is a NetworkManager issue then. Did you see the first comment from the link I gave you?

If you are using localhost for the Pi's DNS, and it resolves reverse lookups like you have shown when you manually changed the resolver, then when FTL re-resolves the hostnames of the clients they will be correct (they are cached to prevent spamming of reverse lookup queries).

1 Like
11

Yea, I saw. NetworkManager is expletive screwy (see below). But it doesn't matter, I can fight that battle separately.

It works now

I've managed to get NM to create a resolv.conf that looks like this:

[root@pihole network-scripts]# cat /etc/resolv.conf
# Generated by NetworkManager
search agpllc.local
nameserver 127.0.0.1
[root@pihole network-scripts]#

So now it looks like the dashboard is getting populated with dns names. Is there a way to force FTL to re-resolve?

NetworkManager Stinks - edit, it only stinks if you forget to restart it

resolv.conf started looking like this:

[root@pihole NetworkManager]# cat /etc/resolv.conf
# Generated by NetworkManager
search agpllc.local
nameserver 8.8.8.8
nameserver 8.8.4.4

The link above says just remove the "DNS1" and "DNS2" entries from NetworkManager.conf. If I do that, I end up with resolv.conf without the nameserver lines, but still gets rewritten by NM:

[root@pihole NetworkManager]# cat /etc/resolv.conf
# Generated by NetworkManager
search agpllc.local

I couldn't figure out where the 'search' line was configured. Also, the NM documentations seem to say that if you put

[main]
dns=none
rc-manager=none

in NetworkManager.conf that'll cause it to leave resolv.conf alone. Apparently that's not true, or something. EDIT: Need to 'service NetworkManager restart' after modifying NetworkManager.conf (duh). Now it leaves resolv.conf alone.

I was able to get resolv.conf looking kinda like I wanted by editing the ifcfg- file with

DNS1=127.0.0.1

Which may be a bit of a hack, but it seems to be working now.

Thanks for the help.

12

Run echo ">reresolve" | nc localhost 4711 to re-resolve hostnames

13
[root@pihole network-scripts]# echo ">reresolve" | nc localhost 4711
unknown command: >reresolve

---EOM---
14

It looks like that command is only available on FTLDNS and newer, so you will just have to either restart FTL or wait:

sudo service pihole-FTL restart
15

Ok, but interesting.

[root@pihole pihole]# service pihole-FTL restart
.
Stopped

rm: cannot remove '/var/run/pihole/FTL.sock': No such file or directory
FTL started!
16

That is somewhat expected (that socket file may not exist)

17
