Pi-Hole DNS doesn't work

Help Community Help
1

Please follow the below template, it will help us to help you!

Some info:

I recently bought a new Raspberry Pi Zero W, installed the latest version of Raspbian Lite (no UI) and installed Pi-Hole as per the instructions from the website. After install was complete, I tried to manually set the DNS on 1 client (Windows 10). I apologize if this question is a duplicate, however after hours of searching and trying I decided to ask for help instead.

Expected Behaviour:

Running nslookup google.com or accessing any website produces any meaningful results. Both client and Raspberry Pi should return something. Alternatively I left DNS as automatic and ran the command nslookup google.com 192.168.8.108 (whole local network is on 192.168.8.* with modem occupying 1, raspberry 108 and Windows 10 client 105).

Actual Behaviour:

nslookup returns DNS request timed out on client. Running the command on Raspberry Pi returns valid results.

Debug Token:

https://tricorder.pi-hole.net/li7ngjug66

I've tried reinstalling from scratch in fear I somehow did something wrong, but that doesn't help either. I tried changing my upstream DNS multiple times (basically every possible choice), I tried changing interface listening behaviour to every possible choice. I don't want to use Pi-Hole's DHCP and I already tried setting it as my router's default DNS (if the client would somehow have issues with the DNS change), but nothing seems to work.

Any help would be greatly appreciated.

2

You pointed W10 to your RPI as DNS server?
Simple insight if your PiHole serves as DNS server and if your RPI DNS system is up and running properly can be obtained with DNS Benchmark
Don't forget to add your RPI address in DNS Benchmark first.

3

I tried to run DNS Benchmark. And (evidently) it didn't go so well ...

System's nameserver is dead & NOT replying to queries!
It probably comes as no surprise that all of this system's sole DNS resolving nameserver, with the IP address of [192.168.8.108] is apparently dead (at least for the moment) and is not replying to DNS queries since very little of the Internet is accessible without any DNS services.

Oddly enough RPi doesn't have problems running nslookup:

pi@raspberrypi:~ $ nslookup pi-hole.net
Server: fe80::5e78:f8ff:fe93:26fe%2
Address: fe80::5e78:f8ff:fe93:26fe%2#53

Non-authoritative answer:
Name: pi-hole.net
Address: 192.124.249.118

I tried restarting the DNS Resolver in the Pi-Hole's UI, but that didn't do anything.

4

What's the answer on your RPI to dig pihole.net ?
Like

dig pihole.net

; <<>> DiG 9.11.5-P4-5.1+deb10u2-Raspbian <<>> pihole.net
;; global options: +cmd
;; Got answer:
;; ->>HEADER<<- opcode: QUERY, status: NOERROR, id: 50364
;; flags: qr rd ra; QUERY: 1, ANSWER: 0, AUTHORITY: 1, ADDITIONAL: 1

;; OPT PSEUDOSECTION:
; EDNS: version: 0, flags:; udp: 1232
;; QUESTION SECTION:
;pihole.net. IN A

;; AUTHORITY SECTION:
pihole.net. 3600 IN SOA DNS105.REGISTER.COM. root.REGISTER.COM. 120082000 10800 3600 604800 3600

;; Query time: 221 msec
;; SERVER: 127.0.0.1#53(127.0.0.1)
;; WHEN: Sat Dec 05 19:59:26 CET 2020
;; MSG SIZE rcvd: 99

5

Pi-hole is working, but your connection to the internet on that device is not:


*** [ DIAGNOSING ]: Name resolution (IPv4) using a random blocked domain and a known ad-serving domain
[✓] tracker.tagsrvcs.com is 0.0.0.0 via localhost (127.0.0.1)
[✓] tracker.tagsrvcs.com is 0.0.0.0 via Pi-hole (192.168.8.108)
[✗] Failed to resolve doubleclick.com via a remote, public DNS server (8.8.8.8)

*** [ DIAGNOSING ]: Name resolution (IPv6) using a random blocked domain and a known ad-serving domain
[✓] wesolywagonik.pl is :: via localhost (::1)
[✓] wesolywagonik.pl is :: via Pi-hole (fd5c:78f8:9326:fe00:d14e:b583:3ec9:2ec5)
[✗] Failed to resolve doubleclick.com via a remote, public DNS server (2001:4860:4860::8888)
6

Try our actual DNS name.

7

Running the command dig on RPi gives the following output:

pi@raspberrypi:~ $ dig pihole.net

; <<>> DiG 9.11.5-P4-5.1+deb10u2-Raspbian <<>> pihole.net
;; global options: +cmd
;; Got answer:
;; ->>HEADER<<- opcode: QUERY, status: NOERROR, id: 59297
;; flags: qr rd ra; QUERY: 1, ANSWER: 0, AUTHORITY: 1, ADDITIONAL: 1

;; OPT PSEUDOSECTION:
; EDNS: version: 0, flags:; udp: 512
;; QUESTION SECTION:
;pihole.net.                    IN      A

;; AUTHORITY SECTION:
pihole.net.             3600    IN      SOA     DNS105.REGISTER.COM. root.REGISTER.COM. 120082000 10800 3600 604800 3600

;; Query time: 187 msec
;; SERVER: fe80::5e78:f8ff:fe93:26fe%2#53(fe80::5e78:f8ff:fe93:26fe%2)
;; WHEN: Sat Dec 05 20:05:15 CET 2020
;; MSG SIZE  rcvd: 99
8

Looks like you've added some script or function that is manipulating the database as well.

*** [ DIAGNOSING ]: Domainlist (0/1 = exact white-/blacklist, 2/3 = regex white-/blacklist)
   id    type  enabled  group_ids     domain                                                                                                date_added           date_modified        comment
   ----  ----  -------  ------------  ----------------------------------------------------------------------------------------------------  -------------------  -------------------  --------------------------------------------------
   1     0           1  0             0.client-channel.google.com                                                                           2020-12-05 12:41:05  2020-12-05 12:41:05  In order for users on your network to access Googl
   2     0           1  0             1drv.com                                                                                              2020-12-05 12:41:05  2020-12-05 12:41:05  It is actually a legitimate Microsoft owned domain
   3     0           1  0             2.android.pool.ntp.org                                                                                2020-12-05 12:41:05  2020-12-05 12:41:05  This domain is a part of The pool.ntp.org project
   4     0           1  0             akamaihd.net                                                                                          2020-12-05 12:41:05  2020-12-05 12:41:05  This domain is owned by Akamai Technologies which
   5     0           1  0             akamaitechnologies.com                                                                                2020-12-05 12:41:05  2020-12-05 12:41:05  This domain is owned by Akamai Technologies which
   6     0           1  0             akamaized.net                                                                                         2020-12-05 12:41:05  2020-12-05 12:41:05  This domain is owned by Akamai Technologies which
   7     0           1  0             amazonaws.com                                                                                         2020-12-05 12:41:05  2020-12-05 12:41:05  Amazon Web Services (AWS) is a subsidiary of Amazo
   8     0           1  0             android.clients.google.com                                                                            2020-12-05 12:41:05  2020-12-05 12:41:05  Google Play Store and few devices (especially Andr
   9     0           1  0             api.ipify.org                                                                                         2020-12-05 12:41:05  2020-12-05 12:41:05  It is used to get your public IP address programma
   10    0           1  0             app-api.ted.com                                                                                       2020-12-05 12:41:05  2020-12-05 12:41:05  Used by ted.com streams. - qjz9zk
   11    0           1  0             api.rlje.net                                                                                          2020-12-05 12:41:05  2020-12-05 12:41:05  Used to deliver contents on video straming apps on
   12    0           1  0             appleid.apple.com                                                                                     2020-12-05 12:41:05  2020-12-05 12:41:05  Used to sign in t your Apple account. - qjz9zk
   13    0           1  0             apps.skype.com                                                                                        2020-12-05 12:41:05  2020-12-05 12:41:05  Used to make group calls, group chats etc. on Skyp
   14    0           1  0             appsbackup-pa.clients6.google.com                                                                     2020-12-05 12:41:05  2020-12-05 12:41:05  Used to backup device settings and app data. - qjz
   15    0           1  0             appsbackup-pa.googleapis.com                                                                          2020-12-05 12:41:05  2020-12-05 12:41:05  Used to backup device settings and app data. - qjz
   16    0           1  0             apt.sonarr.tv                                                                                         2020-12-05 12:41:05  2020-12-05 12:41:05  Sonarr is a PVR for Usenet and BitTorrent users. I
   17    0           1  0             aspnetcdn.com                                                                                         2020-12-05 12:41:05  2020-12-05 12:41:05  Owned by Microsoft. Used to deliver files such as
   18    0           1  0             attestation.xboxlive.com                                                                              2020-12-05 12:41:05  2020-12-05 12:41:05  Owned by Microsoft. Used for Xbox updates, game do
   19    0           1  0             ax.phobos.apple.com.edgesuite.net                                                                     2020-12-05 12:41:05  2020-12-05 12:41:05  Used by Apple Photos. - qjz9zk
   20    0           1  0             brightcove.net                                                                                        2020-12-05 12:41:06  2020-12-05 12:41:06  Video delivery systems, popular in entertainment a
   21    0           1  0             c.s-microsoft.com                                                                                     2020-12-05 12:41:06  2020-12-05 12:41:06  Used to deliver fonts. - qjz9zk
   22    0           1  0             cdn.cloudflare.net                                                                                    2020-12-05 12:41:06  2020-12-05 12:41:06  Used to deliver static files over CloudFlare CDN.
   23    0           1  0             cdn.embedly.com                                                                                       2020-12-05 12:41:06  2020-12-05 12:41:06  Embedly is used to embed videos, images and rich m
   24    0           1  0             cdn.optimizely.com                                                                                    2020-12-05 12:41:06  2020-12-05 12:41:06  optimizely.com is a progressive delivery and exper
   25    0           1  0             cdn.vidible.tv                                                                                        2020-12-05 12:41:06  2020-12-05 12:41:06  Video delivery systems, popular in entertainment a
   26    0           1  0             cdn2.optimizely.com                                                                                   2020-12-05 12:41:06  2020-12-05 12:41:06  optimizely.com is a progressive delivery and exper
   27    0           1  0             cdn3.optimizely.com                                                                                   2020-12-05 12:41:06  2020-12-05 12:41:06  optimizely.com is a progressive delivery and exper
   28    0           1  0             cdnjs.cloudflare.com                                                                                  2020-12-05 12:41:06  2020-12-05 12:41:06  Used to deliver static files over CloudFlare CDN.
   29    0           1  0             cert.mgt.xboxlive.com                                                                                 2020-12-05 12:41:06  2020-12-05 12:41:06  Owned by Microsoft. Used for Xbox updates, game do
   30    0           1  0             clientconfig.passport.net                                                                             2020-12-05 12:41:06  2020-12-05 12:41:06  Owned by Microsoft. Used in Windows Store. - qjz9z
   31    0           1  0             clients1.google.com                                                                                   2020-12-05 12:41:06  2020-12-05 12:41:06  Used in Google Maps and other Google services. - q
   32    0           1  0             clients2.google.com                                                                                   2020-12-05 12:41:06  2020-12-05 12:41:06  Used in Google Maps and other Google services. - q
   33    0           1  0             clients3.google.com                                                                                   2020-12-05 12:41:06  2020-12-05 12:41:06  Used in Google Maps and other Googl
9

Yes, I followed this link:

10

pi-hole.net 8msec
pihole.net 221msec
Indeed.
Sorry for being offtopic here.

And @tavbi , a tip.
In initial setup always follow the instructions.
When things are running fine, then adapt to your own likings.

1 Like
11

Okay, I'll move this over to Community Help since you have outside scripting manipulating Pi-hole.

12

Well, fair point, though even without the whitelist, it still isn't really working. I'll try to reinstall the whole system without the added step and I'll post whether there's any change ...

13
[✗] Failed to resolve doubleclick.com via a remote, public DNS server (8.8.8.8)
[✗] Failed to resolve doubleclick.com via a remote, public DNS server (2001:4860:4860::8888)

That's the issue that needs to be fixed. Pi-hole is working, it's responding with 0.0.0.0 for a domain that we know should be blocked. The problem is a query to a DNS server off your network (an upstream DNS server) is failing. That's a networking problem. And if that is not solved then a re-install of everything won't fix it.

14

You weren't off-topic. My comment was that pihole.net won't return a valid IP. pi-hole.net will.

15

Indeed, clean reinstall didn't bring about any difference.
https://tricorder.pi-hole.net/tk4f7qdk1s

16

Yes, same exact condition:


*** [ DIAGNOSING ]: Name resolution (IPv4) using a random blocked domain and a known ad-serving domain
[✓] phox2ey.bid is 0.0.0.0 via localhost (127.0.0.1)
[✓] phox2ey.bid is 0.0.0.0 via Pi-hole (192.168.8.104)
[✗] Failed to resolve doubleclick.com via a remote, public DNS server (8.8.8.8)

*** [ DIAGNOSING ]: Name resolution (IPv6) using a random blocked domain and a known ad-serving domain
[✓] prod.zenkube.com is :: via localhost (::1)
[✓] prod.zenkube.com is :: via Pi-hole (fd5c:78f8:9326:fe00:2c9a:810d:d9a3:d0f2)
[✗] Failed to resolve doubleclick.com via a remote, public DNS server (2001:4860:4860::8888)
17

Well, as previously stated, changing the upstream DNS doesn't help. And this time it's a clean, out-of-the box solution with only defaults set. All devices on my network work properly (since I obviously can post this from my computer), but for some reason Pi-Hole doesn't work properly.

Could it be due to some modem settings? Or did I miss anything there? Could it be because I'm using the wireless model of RPi Zero, instead of connecting it to ethernet? As far as I could see, people made it work using this RPi model, but maybe there's some extra step I missed?

You probably noticed it in the logs, but the installation was complaining about the OS - although I used the official Raspberry Pi tool to download the latest OS version & I ran sudo apt-get update -y and sudo apt-get upgrade -y before installing Pi-Hole. I had to use the PIHOLE_SKIP_OS_CHEKC=true flag to install it on the device ...

18
*** [ DIAGNOSING ]: Operating system
[i] dig return code:  9
[i] dig response:  ;; connection timed out; no servers could be reached

Same root cause:
Your Zero isn't able to resolve DNS through public DNS servers, hence the download of the supported OS versions fails.

Let's check DNS resolution from some client in your network (not your Zero).

Executed on a client, what's the output of:

nslookup pi.hole

nslookup flurry.com 192.168.8.104

nslookup flurry.com 80.241.218.68
19
nslookup pi.hole
Server:  UnKnown
Address:  103.86.96.100

*** UnKnown can't find pi.hole: Non-existent domain

nslookup flurry.com 192.168.8.104
DNS request timed out.
    timeout was 2 seconds.
Server:  UnKnown
Address:  192.168.8.104

DNS request timed out.
    timeout was 2 seconds.
DNS request timed out.
    timeout was 2 seconds.
DNS request timed out.
    timeout was 2 seconds.
DNS request timed out.
    timeout was 2 seconds.
*** Request to UnKnown timed-out

nslookup flurry.com 80.241.218.68
Server:  dismail.de
Address:  80.241.218.68

Name:    flurry.com
Address:  0.0.0.0

This seems to be the output from the client

20

Your clients are not using Pi-hole for DNS, but rather 103.86.96.100.
That's one of NordVPN's DNS servers.

EDIT:
That's also a bit unexpected, since your DHCP server is distributing its own IP as local DNS server:

*** [ DIAGNOSING ]: Discovering active DHCP servers (takes 10 seconds)
   Scanning all your interfaces for DHCP servers
   * Received 286 bytes from wlan0:192.168.8.1
      dns-server: 192.168.8.1

nslookup fails to contact your Pi-hole at 192.168.8.104.

Considering both results could imply you are trying to use Pi-hole as a custom DNS server in a VPN setup.

If that's the case, you'd have to consult with your VPN provider if and how a local custom DNS server can be configured.
You should also make sure Pi-hole's IP address is accessible from its prospective clients.
